GLOW PLUG
Dear Customer, Dear Dealer,
First of all, congratulations to choose ISKRA Diesel Cold Start Components.
Since the aspect of environmental suitability has gained the leading role in
automotive field, a struggling effort has been made through the market to
satisfy ever greater emission demands. Our engineers are in a constant pursuit
for better products.
New generation of Flash Start System (FSS) glow plugs are controlled with
glow plug control unit (GPCU). In comparison with standard 11V glow plugs,
the heat-up time is considerably shorter.
u
Pin or Threaded Connector
Pins or Terminals are protected with special
material treatment to resist corrosion and
ensure reliable power connection.
v
Insulator
The Glow Plug insulator has excellent strength,
insulation and thermal conductivity to avoid of
any possible short circuit.
w
Housing
Dimensions of Glow plug housing is important
for engine inbuilt. At the same time its functions
is to provide heat resistance and also to protect
inside parts.
x
Seal
A rubber seal prevents any further air contact
which could lead to coil corrosion.
y
Insulation
Magnesium oxide powder is used for insulation
material, which has also excellent features as
heat conductor.
z
Electrode
Inside of the Glow Plug, electrode provides
supply of electrical energy to the coils.
{
Regulating Coil
The main function of the Regulating Coil is to
effective control current draw for fast heat-up
of the Heating Coil.
|
Coil Connection
Laser welding technology assure reliable
connects between Heating and Regulating coils
and maintain their position at all times and
ensure consistent resistance features.
}
Heating Coil
A shorter coil inside of the end of the Glow
Plug enable a flash start even in very cold
conditions. The post-heating temperature could
be extended also after cold start, which results
to significant lower engine emissions.
~
Heater tube
The reduced diameter of heater tube ensures
improved heating efficiency and overall
excellent performance.
The basic scheme of glow plug
